FL SWITCH 2000 / FL NAT 2000
54 / 226
PHOENIX CONTACT 108997_en_04
Connection data
Connection method Push-in spring connection
Note on the connection method Use only copper connecting cables providing the permitted
temperature range (-40°C ... 75°C).
pluggable Yes
Conductor cross section solid min. 0.25 mm²
Conductor cross section solid max. 1.5 mm²
Conductor cross section flexible min. 0.25 mm²
Conductor cross section flexible max. 1.5 mm²
Conductor cross section AWG min. 24
Conductor cross section AWG max. 16
Stripping length 9 mm
Interface: Ethernet (RJ45)
Number of interfaces 5
Connection method RJ45
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100 Mbps
Transmission length 100 m (per segment)
Supply voltage
Supply voltage 24 VDC (single)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 18 VDC ... 32 VDC
Typical current consumption 165 mA (at U
S
= 24VDC and 25°C ambient temperature)
Max. current consumption 0.3 A (At U
S
= 18 V DC and 60°C ambient temperature)
Maximum power dissipation for nominal condition 3.96 W (At U
S
= 18 V DC and 60°C ambient temperature)
Test section for one minute 500 VDC
Mechanical tests
Mechanical tests Free fall in accordance with EN61131-2
Vibration (operation) 2g, according to IEC60068-2-6
Vibration (storage/transport) 2g, criterion 1 according to IEC 60068-2-6
Shock (operation) 30g (EN60068-2-27)
Conformity with EMC directives
Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Conducted noise emission EN 61000-6-2 EN 61000-6-4 (conducted interference) Class A
Interference emission EN 61000-6-2 EN 61000-6-4 (interference) Class A
Immunity to burst EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A
Immunity to EF EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion
A
