FL SWITCH 2000 / FL NAT 2000
56 / 226
PHOENIX CONTACT 108997_en_04
Housing material Polycarbonate fiber reinforced
MAC address table 8k
MTTF 507.8 Years (SN 29500 standard, temperature 25 °C,
operating cycle 21 % (5 days a week, 8 hours a day))
MTTF 246.55 Years (SN 29500 standard, temperature 40 °C,
operating cycle 34.25 % (5 days a week, 12 hours a day))
MTTF 56.66 Years (SN 29500 standard, temperature 55 °C,
operating cycle 100 % (7 days a week, 24 hours a day))
General data
Connection data
Connection method Push-in spring connection
Note on the connection method Use only copper connecting cables providing the permitted
temperature range (-40°C ... 75°C).
pluggable Yes
Conductor cross section solid min. 0.25 mm²
Conductor cross section solid max. 1.5 mm²
Conductor cross section flexible min. 0.25 mm²
Conductor cross section flexible max. 1.5 mm²
Conductor cross section AWG min. 24
Conductor cross section AWG max. 16
Stripping length 9 mm
Interface: Ethernet (RJ45)
Number of interfaces 8
Connection method RJ45
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100 Mbps
Transmission length 100 m (per segment)
Supply voltage
Supply voltage 24 VDC (single)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 18 VDC ... 32 VDC
Typical current consumption 180 mA (at U
S
= 24VDC and 25°C ambient temperature)
Max. current consumption 0.35 A (At U
S
= 18 V DC and 60°C ambient temperature)
Maximum power dissipation for nominal condition 4.86 W (At U
S
= 18 V DC and 60°C ambient temperature)
Test section for one minute 500 VDC
Mechanical tests
Mechanical tests Free fall in accordance with EN61131-2
