FL SWITCH 2000 / FL NAT 2000
58 / 226
PHOENIX CONTACT 108997_en_04
Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing)
Air pressure (operation) 86 kPa ... 108 kPa (1500m above sea level)
Air pressure (storage/transport) 86 kPa ... 108 kPa (1500m above sea level)
Ambient conditions
General data
Mounting type DIN rail
Type AX
Functional grounding
Weight 240 g
Housing material Aluminum
MAC address table 8k
MTTF 693.88 Years (SN29500 standard, temperature25°C,
operating cycle21%)
MTTF 315.58 Years (SN29500 standard, temperature40°C,
operating cycle34.25%)
MTTF 42.59 Years (SN29500 standard, temperature55°C, operating
cycle100%)
Connection data
Connection method Push-in spring connection
Note on the connection method Use only copper connecting cables providing the permitted
temperature range (-40°C ... 75°C).
pluggable Yes
Conductor cross section solid min. 0.25 mm²
Conductor cross section solid max. 1.5 mm²
Conductor cross section flexible min. 0.25 mm²
Conductor cross section flexible max. 1.5 mm²
Conductor cross section AWG min. 24
Conductor cross section AWG max. 16
Stripping length 9 mm
Interface: Ethernet (RJ45)
Number of interfaces 8
Connection method RJ45
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100 Mbps
Transmission length 100 m (per segment)
