FL SWITCH 2000 / FL NAT 2000
80 / 226
PHOENIX CONTACT 108997_en_04
Interface: Ethernet FO
Number of interfaces 1
Connection method SC
Transmission physics multi-mode fiberglass
Transmission speed 100 Mbps (full duplex)
Transmission length 11000 m (fiberglass with F-G 62.5/125 0.7 dB/km F1000)
Transmission length 6400 m (fiberglass with F-G 50/125 0.7 dB/km F1200)
Transmission length 3000 m (fiberglass with F-G 62.5/125 2.6 dB/km F600)
Transmission length 2800 m (fiberglass with F-G 50/125 1.6 dB/km F800)
Wavelength 1300 nm
Supply voltage
Supply voltage 24 VDC (redundant)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 9 VDC ... 57 VDC
Typical current consumption 220 mA (at U
S
= 24VDC and 25°C ambient temperature)
Max. current consumption 1.4 A (U
S
= Min, T
amb
= Max, DO
I
= Max)
Maximum power dissipation for nominal condition 5.85 W (U
S
= Min, T
amb
= Max, DO
I
= Max)
Test section for one minute 500 VDC
Mechanical tests
Mechanical tests Free fall in accordance with EN61131-2
Vibration (operation) in acc. with IEC 60068-2-6: 5g, 150 Hz
Vibration (storage/transport) 5g, 150 Hz, in acc. with IEC 60068-2-6
Shock (operation) 30g (EN60068-2-27)
Conformity with EMC directives
Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Conducted noise emission EN 61000-6-2 EN 61000-6-4 (conducted interference) Class A
Interference emission EN 61000-6-2 EN 61000-6-4 (interference) Class A
Immunity to burst EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A
Immunity to EF EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion
A
Immunity to ESD EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B
Immunity to surge EN 61000-6-2 EN 61000-4-5 (surge) Criterion B
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
Approvals / Certificates
ATEX II 3 G Ex ec IIC T4 Gc
IECEx Ex ec IIC T4 Gc
UL, USA UL 60079-0, Ed.6 / UL 60079-7, Ed.5
