FL SWITCH 2000 / FL NAT 2000
92 / 226
PHOENIX CONTACT 108997_en_04
Ambient conditions
Degree of protection IP20
Protection class III, VDE 0106
Degree of pollution 2
Ambient temperature (operation) -40 °C ... 70 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing)
Air pressure (operation) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Air pressure (storage/transport) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Free from substances that could impair the application of
coating
Yes
General data
Mounting type DIN rail
Type AX Book type
Functional earth ground The functional ground of the module is achieved when the
module is snapped onto the DIN rail.
Weight 260 g
Housing material Polycarbonate fiber reinforced
MAC address table 8k
MTTF 343.16 Years (SN 29500 standard, temperature 25 °C,
operating cycle 21 % (5 days a week, 8 hours a day))
MTTF 153.37 Years (SN 29500 standard, temperature 40 °C,
operating cycle 34.25 % (5 days a week, 12 hours a day))
MTTF 18.66 Years (SN 29500 standard, temperature 70 °C,
operating cycle 100 % (7 days a week, 24 hours a day))
Signal contact
Output name Digital output
Control voltage range 9 VDC ... 57 VDC
Current carrying capacity typ. 100 mA
max. 0.7 A (1 minute)
Connection data
Connection method Push-in spring connection
Note on the connection method Use only copper connecting cables providing the permitted
temperature range (-40°C ... 75°C).
pluggable Yes
Conductor cross section solid min. 0.25 mm²
Conductor cross section solid max. 1.5 mm²
Conductor cross section flexible min. 0.25 mm²
