If no synchronization signal is input or the input signal is under 60Hz (50Hz) during steps 3 to 7, or
the synchronization signal is lost, the display shows "NO SYNC INPUT".
If steps 3 through 7 are done inputting a signal over 480,000 Hz , the display shows “OVER SYNC
INPUT”.
In either case, you cannot record normally.
•
A minute error occurs in the input synchronization signal due to the construction of the internal
circuitry of this function.
An error of ±10 ns occurs for the input synchronization signal in the actual operation.
Since the frame rate display value on the monitor is in 1Hz units, the error may be shown larger than
the actual operation (an error of about ±1-5Hz is produced).
For example, when performing external device synchronization inputting a synchronization signal
of 10000Hz, the monitor display error is:
10,000 Hz ±1Hz = 9,999 fps to 10,001 fps.
61 FASTCAM SA-Z Hardware Manual
