(4) Press the Data Selector <2>. The arrow symbol starts flashing.
(5) Press the Data Selector <2> and adjust the desired frequency (the desired frequency is displayed
next to the f symbol) and press it for confirmation.
NOTICE
With the burst function (burst frequency between 1 and 10 Hz) activated simultan-
eously, you can only choose a selective frequency between 70 and 200 Hz or the fre-
quency band 70 - 150 Hz. The frequency band 1 - 150 Hz is not available.
3.3.9 (TENS) Transcutaneous Electric Nerve Stimulation
Definition Transcutaneous electric nerve stimulation
Application
• Pain therapy for chronic neuralgia and myalgia
Menu for Current Mode TENS
Current Mode TENS: monophase Current Mode TENS: biphase
Parameters for Current Mode TENS
Polarity switch to switch the polarity of the two electrodes (the sign in the intensity dis-
play changes accordingly); can be adjusted separately for both channels.
Switching from monophase to biphase pulse emission.
Pulse time Ti (80 - 500 µs)
Burst frequency (1 - 10 Hz)
Frequency bands 1 - 150 Hz, 70 - 150 Hz or selective frequency 1- 200 Hz
Pulse shape Square pulse
PHYSIOMED ELEKTROMEDIZIN AG
3 Overview of Current Modes
IONOSON-Basic 23
