Piazzetta MP 973 - Dimensional Diagram Firebox MP 973; Accessories and Equipment

DT1020394-00
2.4 dIMENSIONAL dIAGRAM FIREbOx MP 973
35,5÷38,5
61,5
148,7÷151,5
35÷38
60,5
20,5÷23,5
7,7 Outlet ø 8
42 42
66
68
0,8
7
46
52,5
70,5 9,5
92
29,5÷32,5
Fig. 26
DT2011767-00
2.5 ACCESSORIES ANd EqUIPMENT
Description
Room sensor NTC 10K Provided
Cable L=200 Schuko IEC Provided
LCD Remote-control Provided
Door handle tool Provided
Grate bafe plate Provided
Thermodur spray paint can Provided
Door in plasterboard for lining wall Optional
Front pellet feed kit Optional
Pipes and elbows for connection to the ueway Optional
Inspection tee Ø 80 mm r.h. Optional
Inspection tee Ø 80 mm l.h. Optional
Firebox steel frame with black paint for application to plasterboard Optional
GPRS module for remote appliance control Optional
H072047UK0 / DT2001513 – 04
16
English
Dimensions in cm
