DT2010222-07
6.6 CONTROL PANEL
1
2
3
1
3
5
2
8
7
4
6
Fig. 62
The stove is tted with a digital control panel to operate stove functions
when the LCD remote control is unavailable.
The various functions of the control panel are listed below.
NUMBER KEY / DISPLAY DESCRIPTION
1 Key ON/OFF Allows you to start up or shut down the product manually.
2 ON/OFF Led If the LED lights up, it indicates that the stove is lit.
3 Key INCREASE POWER Allows you to increase the power setting. You can choose between the two available settings, P1-P3.
4 INCREASE POWER Led
The LED lights up when the power-increase key is pressed and indicates that the power has been
increased.
5 Key DECREASE POWER Allows you to decrease the power setting. You can choose between the two available settings, P1-P3.
6 DECREASE POWER Led
The LED lights up when the power-decrease key is pressed and indicates that the power has been
decreased.
7 SAFETY DEVICE Led
If the LED lights up, it indicates that a safety device has activated. After approx. 60 seconds the alarm
signal will sound. In the event of activation proceed as follows:
- turn off the stove by pressing the ON/OFF key for several seconds;
- the alarm signal will stop;
- wait until you are sure that combustion of any pellets left in the grate has ceased;
- wait for the stove to cool, then check for and remove whatever has activated the safety device.
Finally, after having cleaned the grate, restart the stove by pressing the ON/OFF key.
8
RADIO SIGNAL EMISSION
Led
The led lights up when the stove receives data from the remote control.
DT2010469-04
6.7 SETTING ThE LANGUAGE
HOW TO SET THE LANGUAGE
Function Action Display message
Selecting the
language menu
Press the MENU key, then using the SELECT MENU key SELEZIONA
LINGUA and conrm with the SET key
1
