Piazzetta MP 973 - Installing the Y-Element (Optional)

• The ducting of heat to adjoining rooms is at the user’s discretion
according to requirements.
• The Y-element, designed to double hot air delivery, may be tted onto
one or both fans at the time the stove is installed.
• If just one Y-element is used, it is more convenient to t it onto the
right fan (as seen from the rear). If two Y-elements are to be used,
rst work on the left fan and then on the right (as seen from the rear
g. 49).
- To install, proceed as follows:
- Fit the hose to the Y-element using the clip provided in the kit (Fig.
50).
- Fit the Y-element to the fan outlet using the screws provided in the
kit (Fig. 50).
- Fit the second hose to the Y-element using the clip provided in the
kit (Fig. 50).
- Repeat the above steps for the other fan if two Y-elements are being
used.
- Move the stove closer to the wall and, using the clips provided in the
kit, x the two hoses to the walled ducting ttings (Fig. 51);
- Put the stove in its nal location, complying with the minimum
safety distances (see section “MINIMUM SAFETY DISTANCES”).
DT2010347-01
5.6 INSTALLING ThE y-ELEMENT (OPTIONAL)
Left fan
Right fan
Back side
view
Y connector
Flexible pipe
Coupling
Clip
Flexible pipe
Fig. 49
Fig. 50
Fig. 51
