SELECT UNIT
Function Action Display message
Select UNIT function
Open the ap and press the SET and OPT keys simultaneously. Using the
SELECT MENU key choose one of the eight transmission units (0-1-2-3-4-
5-6-7). Standard setting on pellet stoves is 0
SELECT
UN IT 2
SEARCH
FIELD
UN IT 2
L OADED
1
Restart stove
Disconnect the power cable. reconnect it and within ve seconds press
the ON/OFF key, keeping it pressed down for approximately 3-4 seconds.
An audible beep indicates the successful change of unit.
Two display pages will appear in sequence while the remote control will
return to the initial display.
SELECT
UN IT 2
SEARCH
FIELD
UN IT 2
L OADED
1
SELECT
UN IT 2
SEARCH
FIELD
UN IT 2
L OADED
1
a Unit storage remains as set even without batteries.
DT2040072-05
DT2010248-04
6.18 MOdIFyING ThE TRANSMISSION UNIT
If two pellets stoves of the same model are installed close to each other and the remote control beam activates both simultaneously, it is possible to
modify the transmission unit when the stove has been shut down by proceeding in the following way
DT2010231-05
6.19 MULTIFUOCO SySTEM OPERATION
The pellet stove with “Multifuoco System” is equipped with one/two fans depending on the model which oversee hot air diffusion.
This provision enables multiple channelled hot air diffusion solutions, allowing the user freedom of choice depending on adjacent rooms to be heated.
Below, you will nd a general and concise description of the operation of the Multifuoco System supplied.
It is possible to set the “Multifuoco System” according to four speeds to match fan operation to the ducting solution selected.
These speeds are represented by the values 01, 02, 03, 04 which appear in the row under the display and small rectangles numbered from 1 to 4
in the row above.
When switching from speed 01 to speed 04, the fan air ow increases.
Once the speed of the Multifuoco System has been set, it is possible to select a higher or lower heat quantity by selecting from the ve appliance
power levels: P1, …, P5.
In the same way, more heat is provided by the appliance when switching from power P1 to power P5.
It is left to the user, based upon their own experience of using the stove, to set the Multifuoco speed and the appliance power.
These selections should be based upon the ducting distance and the desired heating temperatures (by way of example, the longer the channelling
route, the higher the set speed of the Multifuoco System).
For each solution described in the chapter INSTALLATION in the section “MULTIFUOCO SYSTEM”, there is a recommendation for the Multifuoco
fan speed.
If SOLUTION 1 is selected, it is recommended that fan speed “01”is selected on the control panel.
If SOLUTION 2 is selected, a greater thrust of hot air will be required and in this case fan speed “02”should be chosen on the control panel.
