English
32
F
unction
A
ction
D
isplay
S
et desired power for
first operating cycle.
P
ress SELECT MENU to set the desired power
(for example you want power setting 1). Confirm
b
y pressing the SET key.
Set room
temperature for first
operating cycle.
Press SELECT MENU to set the desired room
temperature (for example, you want a room
temperature of 25°C). Confirm by pressing the
SET key. When the desired temperature has been
reached the stove automatically reverts to power
setting P1 and the temperature can be read on the
remote or on the stove - see Multiconfort menu.
Set desired
Multifuoco fan speed
for first operating
cycle.
Press SELECT MENU to set the desired fan
speed (for example, you want fan speed setting 1).
Confirm by pressing the SET key. When
programming the timer on the P960-P960F-P961
stove it is not possible to set separate fan speeds.
After having programmed the first operating cycle you may, if you wish,
proceed with programming the second operating cycle by going through
the settings in the order as described above. The number 2 appears on
the display to indicate the second operating cycle.
SET W
POWER 2
01
DT2040068-01
START W
PROGRAM 2
06:00
WEEKEND PROGRAMME
Function Action Display
Select set chrono
menu
Press the MENU key. Using the SELECT MENU
key select the SET CHRONO menu and confirm by
pressing the SET key.
Select weekend-
programme
Using the SELECT MENU key select the
PROGRAM WEEK-END weekend-programme
menu and confirm by pressing the SET key.
