9 Interfaces
Installation manual PMCprimo Drive2
Page 45
9 Interfaces
All important interfaces of the PMCprimo Drive2 are shown in this chapter. The precise location of
the connectors and terminals can be seen on page 39.
9.1 Power supply
9.1.1 Mains supply (X0)
• Direct to earthed 3~ supply, 230V
-10%
... 480V
+10%,
50 ... 60 Hz, integrated filter
• Fusing (e.g. fusible cut-outs) provided by the user ⇒ page 21
• For single phase operation use L1 and L2!
