10 Commissioning
Page 84
Installation manual PMCprimo Drive2
10.6 Warnings
Faults which occur, but which do not cause a switch-off of the amplifier output stage (BTB/RTO
contact remains closed) , are indicated in the LED display on the front panel by a coded warning
number.
Number Meaning
n01
I²t threshold exceeded
n02
preset regen power reached
n04
response monitoring (watchdog) is active
n05
supply phase missing
n12
HIPFERFACE: motor default values were loaded
n13
mc1p card not functioning correctly
Example of a warning (flashing):
warning n01:
I²t threshold exceeded
