8 Installation
Installation manual PMCprimo Drive2
Page 35
-
8.4 Wiring
Only professional staff who are qualified in electrical engineering are allowed to install the
PMCprimo Drive2.
The installation procedure is described as an example. A different procedure may be sensible or
necessary, depending on the application of the equipment.
Caution !
Only install and wire up the equipment when it is not live, i.e. when neither the mains
power supply nor the 24 V auxiliary voltage nor the operating voltages of any other
connected equipment is switched on.
Take care that the cabinet is safely disconnected (with a lock-out, warning signs etc.).
The individual voltages will be switched on for the first time during commissioning.
Note !
The ground symbol ;, which you will find in all the wiring diagrams, indicates that
you must take care to provide an electrically conductive connection with the largest
possible area between the unit indicated and the mounting plate in the switchgear cabinet.
This connection is for the effective grounding of HF interference, and must not be confused
with the PE- symbol : (a protective measure to EN 60204).
Use the following connection diagrams:
— Power and control connections: page 37
— Resolver: page 52
— HIPERFACE encoder: page 53
— Encoder emulation ROD: page 54
— Encoder emulation SSI: page 55
— RS232 / PC: page 56
— Power supply: page 45
— Digital signals: page 59
— Analog signals: page 65
— Master encoder: page 69
— Panel/Profibus: page 74
— CAN bus: page 67
