Figure 21-20. Suggested Setup of Heater Operation
Figure 21-21. Wiring Connections for Heater Operation Test
391
12 VOLT
DC
VENT. AIR
BLOWER
FUEL IN
(FROM PUMP)
24" MIN.
6 "
APPROX
TERMINAL
STRIP
2.25 "
DIA. ORIFICE
THERMOMETER
OVERHEAT
(LIMIT) SWITCH
DUCT SWITCH
CYCLING SWITCH
DUCT
DRAIN
HEATER
EXHAUST OUTLET
COMBUSTIONAIR
PRESSURE SWITCH
COMBUSTION
AIR BLOWER
VENTILATING
AIR MANOMETER
COMBUSTION
AIR MANOMETER
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
2 1 - 4 4 - 0 9
Page 21-43
Revised: May 15, 1989
1G10
