CHART 9109. ELECTRICAL SYSTEM COMPONENT LOAD (Sheet 1 of 2)
PIPER AIRCRAFT
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
91-23-00
Page 91-24
Revised: June 20, 1995
4B19
DUTY
1
CYCLE
2
EQUIPMENT CKT.- (AMPS) OPT.
BKR.
X ALTERNATOR FIELD (2) 5 5.0 EA
X STARTER SOLENOID (LEFT
AND RIGHT) 10 10.0
X CIGAR LIGHTER(ACCESSORY) — 8.0
X STARTER — 175.0
X FUEL PUMP (LEFT) 8 0.5
X FUEL PUMP (RIGHT) 8 0.5
X ENGINE GAGES (LEFT) 5 appx. 1.0
X ENGINE GAGES (RIGHT) 5 appx. 1.0
X HYDRAULIC PUMP 25 25.0
X LANDING GEAR CONT. & WARN. 5 —
X LANDING GEAR SOLENOID — 0.8
X GEAR DOWN LIGHTS (3) — Total 0.3
X GEAR UNSAFE LIGHT — 0.08
X GEAR WARN HORN — 0.4
X MASTER CONTACTOR — 0.6
X COMBUSTION HEATER 15 13.0
X PITOT HEAT 15 13.2
X STALL WARNING HORN 5 0.4
X ELECTRIC TURN & BANK 5 0.5
X PITCH TRIM 5 5.0
X LANDING LIGHT (PA-44-180, S/N’S
44-7995001 THRU 44- 8195026, AND
PA-180T, S/N’S 44-8107001 AND UP) 10 8.0
X LANDING LIGHT - 2 BULBS.
(PA-44-180, S/N’ 4495001 AND UP) 15 14.0
Varies on
AVIONICS LIGHTS 5 Avionics
Instls.
X INSTRUMENT PNL. LIGHTS 10 2.5
FLOOD LIGHTS 5
X RED FLOOD — 1.0
X DOME LIGHT — 0.6
X POSITION LIGHTS 10 7.3
1
CONTINUOUS
2
INTERMITTENT
