Figure 55-4. Rudder Installation
1
4
5
6
2
3
1. UPPER RUDDER HINGE
2. RUDDER TRIM TAB
3. TRIM TAB HINGE
4. RUDDER SECTOR
5. RUDDER SECTOR STOP
6. LOWER RUDDER HINGE
7. RUDDER STOP ADJUSTMENT BOLT
2303
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
5 5 - 4 2 - 0 1
Page 55-06
Revised: May 15, 1989
3B15
