Figure 81-2. Turbocharger Installation
A
A
B
B
COMPRESSOR HOUSING
ABSOLUTE
PRESSURE
RELIEF VALVE
COMPRESSOR HOUSING
MOUNTING BRACKET
ABSOLUTE PRESSURE
RELIEF VALVE
GROUND ADJUSTABLE
EXHAUST BYPASS VALVE
EXHAUST TURBINE
HOUSING
REAR VIEW OF ENGINE SHOWING TURBOCHARGER INSTALLATION
GROUND ADJUSTABLE
EXHAUST BYPASS VALVE
EXHAUST TURBINE
HOUSING
VIEW A - A VIEW B - B
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
8 1 - 2 3 - 0 0
Page 81-10
Revised: May 15, 1989
3J12
