DIMENSIONS.
The principle airplane dimensions are shown in Figure 6-1 and are listed in Chart 601.
CHART 601. LEADING PARTICULARS AND PRINCIPLE DIMENSIONS
MODEL PA-44-180 / 180T
ENGINE
Manufacturer Lycoming
Model - Left O-360-E1A6D, (CW), TO-360-E1A6D
2
O-360-A1H6
3
, (CW)
Model - Right LO-360-E1A6D, (CCW), LTO-360-E1A6D
2
LO-360-A1H6
3
, (CCW)
FAA Type Certificate TC 286, E26EA
2
Rated Horsepower 180 HP at S. L., 180 HP at 12,000 ft.
2
Rated Speed 2700 RPM, 2575 RPM
2
Oil Pressure:
Minimum Idling 25 psi
Normal 55 to 95 psi
Starting and Warmup 95 to 100 psi
Maximum 115 psi
Oil, SAE Number See Lubrication Chart
Oil Sump Capacity 6 U.S. Quarts, 8 U.S. Quarts
3
Fuel, Aviation Grade, Minimum Octane 100/130, 100 or 100LL
2
Magnetos, Bendix:
TO and O-360-E1A6D D4RN-2021, D4RN-3021
1
, D4RN-3000
2
LTO and LO-360-E1A6D D4LN-2021, D4LN-3021
1
, D4LN-3000
2
Magnetos, Slick:
O-360-A1H6 4270
3
, 4273
3
LO-360-A1H6 4202
3
, 4230
3
Magneto Timing 25° BTC
1&3
, 20° BTC
2
Magneto Point Clearance .016 ± .001
Spark Plug Gap Setting Refer to Latest Issue of Lycoming
Service Instruction No. 1042
Firing Order 1-3-2-4
Starter — Prestolite (12volt):
Left Engine MZ - 4222
Right Engine MZ - 4220
Alternator — Prestolite (60 amp) ALY - 6421
1&2
Alternator — Prestolite (70 amp) ALX - 84211S
3
Alternator Voltage Regulator, LAMAR B-00288-1, B-00392-1
3
Alternator Overvoltage Relay, WICO FOC-4002B
1&2
NOTE:
1
PA-44-180 ONLY
2
PA-44-180T ONLY
3
PA-44-180, S/N 44-95001 and up.
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
6 - 1 0 - 0 0
Page 6-01
Revised: May 15, 1989
