Figure 32-15. Wheel Brake Assembly
1. BRAKE CYLINDER 7. BRAKE LINNG
2. PISTON 8. RIVET
3. O-RING 9. BACK PLATE
4. FRICTION SPRING 10. TORQUE PLATE ASSEMBLY
5. INSULATOR 11. ANCHOR BOLT
6. PRESSURE PLATE 12. BLEEDER SCREW ASSEMBLY
30-65 BRAKE ASSEMBLY
PC28
A266
30-83 BRAKE ASSEMBLY
EXPANSION
GROOVE
.100
MIN.
.100
MIN.
BRAKE LINING
MINIMUM WEAR
THICKNESS
1
11
12
2
12
4
2
3
6
5
7
7
9
10
11
8
9
10
7
8
7
6
3
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
3 2 - 4 4 - 0 3
Page 32-44
Revised: May 15, 1989
2H12
