SWITCHING.
MAGNETO AND STARTER SWITCHES. (Refer to Figure 74-33.)
The magneto switches and the starter switch are located on a switch panel positioned to the left of the
instrument panel.
R E M O VAL AND INSTA L L ATION OF MAGNETO SWITCHES. (Refer to Chapter 30 for removal and
installation procedures.)
R E M O VAL AND INSTA L L ATION OF STA RTER SWITCH. (Refer to Chapter 39 for removal and
installation procedures.)
Figure 74-33. Magneto and Starter Switches
C274
LINK
J3A
J1BR J2BR
J2BL
J1BL
MAGNETO SWITCHES
(REAR VIEW)
STARTER SWITCHES
(REAR VIEW)
SWITCH PANEL
K1BL
K1BL
K1A
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
7 4 - 3 1 - 0 2
Page 74-28
Revised: May 15, 1989
3G21
PIPER AIRCRAFT
