Figure 73-2. Engine Primer System (PA-44-180)
Figure 73-3. Fuel System Schematic (PA-44-180T)
2286
PA-44-180 INSTALLATION
3 4
5 6 7 8
1
2 13
12 11
10 9
1. CHECK BALL
2. BALL SPRING
3. RETAINER SCREW
4. O-RINGS
5. CYLINDER
6. SEALING SPRING
7. PISTON
8. STOP PIN
9. PUMP HANDLE
10. FACE NUT
11. WASHER
12. LOCK NUT
13. SEALING PIN
3093
1
1
2
3
4
1
2
14
3
6
13
5
4
12
11
9
9
10
10
7
7
8
FUEL SELECTORS
LEFT RIGHT
ENGINE ENGINE
ON ON
OFF OFF
X-FEED X-FEED
8
6
5
12
13
4
4
LEFT
FUEL
CELL
RIGHT
FUEL
CELL
3
2
14
2
1
3
1. PRIMER SOLENOID VALVE
2. PRESSURE SENSOR
3. ENGINE DRIVEN PUMP
4. FILLER PORT
5. FINGER STRAINER
6. ELECTRIC PUMP
7. PRIMER BUTTON
8. FUEL PRESSURE GAUGE
9. FILTER AND SUMP
10. SELECTOR VALVE
11. QUICK DRAIN
12. SCUPPER DRAIN
13. FUEL CELL VENT
14. CARBURETOR
PA - 4 4 - 1 8 0 / 1 8 0 T
AIRPLANE MAINTENANCE MANUAL
7 3 - 1 2 - 0 4
Page 73-04
Revised: May 15, 1989
3F6
PIPER AIRCRAFT
