Figure 51-2. Baggage Compartment Inspection Hole Cutout Details
PIPER AIRCRAFT
PA-44-180/180T
AIRPLANE MAINTENANCE MANUAL
51-11-00
Page 51-05
Added: June 20, 1995
2L13
C
L
FORWARD
AFT
14.99”
2.50”
8.48”
30° TYP
2.28” R
TYP
2.00” R
TYP;M
0.120” HOLE THRU
N0.8 X 38 CRES TRUSS
RECESSED HEAD SHEET
METAL SCREWS (16 REQD.)
COVER (2 REQD)
PIPER P/N 62109-0
10.98”
21.80”
19.11”
