10
EN
ENGLISH
15.
Parts Required:
1 x Hot Plate (#2)
4 x Hot Plate Screws (#3)
Installation:
• Turn the Hot Plate upside-down. Insert a Hot Plate Screw into a corner
hole of the Hot Plate, turning by hand, until it cannot rotate any further
into the nut. Repeat same installation on the other three corner holes.
16.
Parts Required:
1 x Grease Cup (#4)
Installation:
• Open the Firebox lid. Carefully, place the Hot Plate into the Firebox. Once
the Hot Plate is installed, ensure it sits level in the Firebox. Adjust the
height of the Hot Plate Screws, if needed, so the Hot Plate is level.
NOTE: To maintain the searing and grilling performance of your Hot
Plate, regular care and maintenance is required.
• Place the Grease Cup into the Grease Cup housing on the left side of the
Firebox, as shown in the illustration.
17.
Parts Required:
1 x Battery (#G)
Installation:
• Turn the ignition button cap counter-clockwise to remove it. Insert the
Battery into the housing with the positive (+) terminal facing outward.
Screw the ignition button cap back into place to cover.
• The unit is now completely assembled.
Refer to Owner's Manual for Operating Instructions.
16
17
15
3
3
3
3
2
2
4
