Part# Description
1 Firebox (x1)
2 Hot Plate (x1)
3 Hot Plate Leg Screws (x4)
4 Grease Cup (x1)
5 Lid Support (x1)
6 Lid Handle Bezel (x2)
7 Lid Handle (x1)
8 Side Shelf - Left (x1)
9 Side Shelf - Right (x1)
10 Side Shelf Bracket - Left (x2)
11 Side Shelf Bracket - Right (x2)
12 Bottle Opener (x1)
13 Cart Side Panel - Left (x1)
14 Cart Partition (x1)
15 Cart Side Panel - Right (x1)
16 Cart Back Panel (x1)
17 Cabinet Door (x1)
18 Drawer Rails (x1)
19 Drawer Support Bar (x1)
20 Heat Shield (x1)
21 Cart Front Panel (x1)
22 Cart Bottom (x1)
23 Swing Drawer (x1)
24 Drawer Front (x1)
25 Drawer (x1)
26 Locking Caster (x4)
A Screw (x54)
B Screw (x2)
C Locking Washer (x14)
D Washer (x14)
E Screw (x14)
F Screw (x6)
G Battery (x1)
NOTE: Due to ongoing product development, parts are subject to change without notice. Contact
Customer Care if parts are missing when assembling the unit.
