Troubleshooting During
Installation
This section includes troubleshooting information about different issues you may
encounter during the installation process or after your display has been running for
some time. If you are not able to solve your issue in this section, please contact
Planar’s Technical Support team for assistance.
UltraRes LED Codes
The LED on the UltraRes display will show different things, depending on the state of
the display.
System State LED Behavior
Power Up LED blinks on and off every ½ sec until it enters the
ON state.
Standby After the LED is powered on, the LED will be blue
while in Standby mode.
Error LED blinks on for 2 seconds and off for 4 seconds.
Firmware Upgrade LED blinks on for 1 second and off for 1 second.
On LED is off.
