VIP User’s Manual
Configuring VIP from a Web Browser 13
Chapter 4 Configuring VIP from a Web Browser
This chapter explains procedures for configuring VIP from the web browser.
4.1 Http setting mode
This section describes the processes for setting up Internet Telephony Gateway once it has been in-
stalled. Microsoft Explorer version 4 or higher, or Navigator version 4.5 or higher can be used in this
section to view and change parameters.
PC Setup
In order to configure VIP, PC needs to have TCP/IP protocol and a compatible IP Address.
1. Connect VIP to network with a RJ-45 UTP cable. Power it on.
2. Find a PC, for example, Windows 2000. Under Windows 2000, select the Network Neighborhood
icon on the desktop, then select Properties. We will see a screen like below:
3. If a line like the one highlighted ("TCP/IP -> Network Card”) is not listed , select Add-Protocol-
Microsoft-TCP/IP-OK to add it.
4. Select Properties for the “TCP / IP -> Network card” entry. You will see a screen like the following:
5. On the IP Address table, enter values as follows:
To Next Page
