VIP User’s Manual
Application Samples
47
1) set h323 dns_ip <dns_server_ip>:
Assign an effective DNS server IP for domain name resolution.
In this topology, DNS server is a MUST-HAVE parameter.
Note:
Please obtain DNS server from local ISP in order to have best efficiency for name resolution while making
domain name calls.
After adding the DNS server, please use "config store " to save settings, then reboot machine to make the
settings effective.
2) set h323 nat_call on: to have packet correctly resolved in NAT environment, this option MUST be en-
abled.
Network Deployment
DDNS service
planetvip.dyndns.org (61.155.107.86) is applied by XRT-401B on site A,
planetvip2.dyndns.org (216.94.170.66) is applied by XRT-401B on site B.
Other parameters on this connection :
VIP-000 on site A has DMZ, and nat_call enabled
VIP-000 on site B has DMZ, and nat_call enabled.
VIP-000 configuration on site A :
IP configuration :
Please refer to your application environment to fill these parame-
ters.
DNS server section
DNS server settings will not take effect till system reboot.
Dialplan settings
Create an address entry for VIP-000 on site B
VIP configuration (cable connection) on site B:
DHCP section:
net set ip 192.168.0.77
net set mask 255.255.255.0
net set gateway 192.168.0.254
net reset
set h323 dns_ip [dns_ip]
config activate
config store
atpm req
atpm aadd 66 2 8 66 2
atpm hadd 66 2 66
atpm dadd 66 dns planetvip2.dyndns.org
atpm done
atpm store
