VIP User’s Manual
Command Line Interface
54
Task Prompt Type
From the remote host, enter the telnet command
followed by the IP address of VIP you want to ac-
cess.
None
telnet ip_addr
When VIP prompts “Login:”, enter the user name
“administrator”
Login:
administrator
When VIP prompts “Password:”, enter the pass-
word. The default password is “123” unless a
password was previously established using the
net set user_pw command (Refer to the section
describing net set user_pw
chapter for details about the setting password).
Password: password
Upon successfully entered the password, VIP displays greeting message and the following prompts
and you are ready to access the CLI commands.
ITG>
7.3 Command Help
Help for commands is provided by the CLI. Type help to see a listing of the top-level commands.
On most cases, if you enter a command using the wrong number of arguments or inappropriate ar-
guments, the CLI will give further usage.
7.4 Designating IP Address
Some commands require an IP address, which must be designated in a standard format. The IP
address format is 32 bits, written as four octets separated by periods (dotted decimal format) that
are made up of a network section, an optional subnet section, and a host section, as shown in the
following example:
192.168.0.1
7.5 Designating Port Number
Some commands require a telephony port number. VIP designates the first port on TIM slot A as
port number 0, the 2
nd
port as port number 1 and so on. When a TIM is installed in slot B, the first
port is designated as port number 4, the 2
nd
one is designated as port number 5 and so on.
