Chapter E - DIMAX3 DIGITAL SYSTEM ADJUSTMENT
E-2 Planmeca Proline EC X-ray unit
REQUIRED TOOLS
Technical Manual
• Ball phantom (part number 50971). For checking the position of the patient positioning
mechanism and the positioning lights.
• Frankfort plane alignment tool (part number 50977). Used with the ball phantom for check-
ing the position of the Frankfort plane light.
• Sensor alignment tool (part number 10002699).
START
END
PLANMECA No.50971
X-LINE
Y-LINE
Ball phantom
START
END
PLANMECA No.50971
X-LINE
Y-LINE
PLANMECA OY NO.50977
Frankfort plan
e
alignment tool
calibtool.eps
Sensor alignment tool
