Edition: 6/2007 Subject to modifications Manual for 362MC Page: 53
Appendix D2: Profile memories and factory presets
The factory-preset profile memories are assigned to profile nos. 1 to 19. Profiles 20 to 50 can be used to
store the changes carried out in the course of commissioning.
The following table presents the factory presets for the general parameters and profile memory no. 1,
whose settings will facilitate the commissioning start-up procedure for several basic control tasks.
In addition the factory preset profiles for several other important control tasks are as listed:
Profile no. 1
Basic temperature control with PT100 input, motor control valve and controller 1;
(e.g. control of the outlet temperature in the cooling circuit of a main engine).
Factory-preset for controller 1
Profile no. 2
Basic temperature control with PT100, motor control valve and controller 2;
(e.g. control of tank heating in conjunction with 1
st
controller + profile no. 1).
>Hardware extension - 2
nd
relay set - required<
Factory-preset for controller 2
Profile no. 3
Temperature control with 2 x PT100 input, motor control valve and controller 1 with
additional differential trend compensation of the 2
nd
PT100 measuring sensor;
(e.g. control of the outlet temperature of a cooling circuit in a main engine with trend
compensation for the inlet temperature).
Profile no. 4 Temperature control with 2 x PT100 input, motor control valve and controller 1 as
cascade step controller with additional disturbance compensation for a 4-20mA signal
from a measured-value transmitter; (e.g. primary control of outlet temperature in the cooling
circuit of a main engine with secondary control of inlet temperature, whereby a signal proportional
to the machine output is applied as the disturbance variable).
>Functional extension - Disturbance compensation - required<
Profile no. 5
Differential pressure control with difference sensor 4-20mA, motor valve and controller 1;
(e.g. control of throttle valve position downstream of a pump according to pressure difference)
>Hardware modification - 1
st
analogue input as 4-20mA - required<
Profile no. 6
Temperature control with PT100 input, pneumatic control valve and controller 1;
(e.g. control of outlet temperature in the cooling circuit of a main engine)
>Hardware extension - Analogue outputs - required<
Profile no. 7
Control with 4-20mA input, pneumatic control valve and controller 1;
> needs hardware modification for the 1
st
analogue input as 4-20mA and hardware
extension analogue outputs <
Profile no. 8
Basic temperature control 0-500°C with PT100 input and motor control valve;
>Hardware modification - 1
st
analogue input for 0-500°C - required<
Profile no. 9
Temperature control 0-500°C with PT100 input, motor control valve and trend
compensation;
>Hardware modification - 1
st
analogue input for 0-500°C - required<
Profile no. 10
Temperature control with PT100 input, motor control valve and extern setpoint input 0-10V;
> needs special analogue input 3 with 0-10V <
Profile no. 11
Temperature control with PT100 input, motor control valve, extern setpoint input 0-10V
and trend compensation;
> needs special analogue input 3 with 0-10V <
Profile no. 12
Differential pressure control with 2 pressure sensors 4-20mA, motor valve and controller 1;
(e.g. control of throttle valve position downstream of a pump according to pressure difference)
>Hardware modification - 1
st
analogue input as 4-20mA - and Functional extension -
Differential actual value - required<
""
""
"
""
""
"
Please use a copy of sheet Prof-No 1 to document your settings and changes.
All current Profiles you will find at www.pleiger-elektronik.de/downloads
""
""
"
