PH-2 SERVICE MANUAL
4. TECHNICAL SPECIFICATIONS
4 TECHNICAL SPECIFICATIONS
4.1 ELECTRICAL
PH-2, Single Phase, 208-240V
Pressure Heater Size Electrical Consumption
2,000PSI
7.5kW(3.75kW/side) 61A
9.0kW(4.5kW/side) 67A
10.5kW(5.25kW/side) 72A
PH-2, Three Phase, 208-240V
Pressure Heater Size Electrical Consumption
2,000PSI
7.5kW(3.75kW/side) 40A
9.0kW(4.5kW/side) 46A
10.5kW(5.25kW/side) 51A
PH-2, Three Phase, 400V
Pressure Heater Size Electrical Consumption
2,000PSI
7.5kW(3.75kW/side) 40A
9.0kW(4.5kW/side) 46A
10.5kW(5.25kW/side) 51A
Material Heater Power Power Consumption
3.75kW/side(3x1250W/side) 7.5kW
4.50kW/side(3x1500W/side) 9.0kW
5.25kW/side(3x1750W/side) 10.5kW
Hose Transformer Power Consumption
70V 2KVA
90V 3KVA
120V 5KVA
Electrical Motor Power Consumption
PH-2 3hp
CAUTION! Inside the console is a Terminal Strip for connect-
ing the main power (wire not supplied) to the PH Series Pro-
portioner. This electrical connection must be made only by a
qualified electrician.
REVISION 1.2 10
