PMC PH-2 - Hydraulic Cylinder Rebuild Kit

POLYURETHANE
MACHINERY
CORPORATION
PH-2 SERVICE MANUAL
15. PARTS IDENTIFICATION
HYDRAULIC CYLINDER ASSEMBLY (HI-05336)
ITEM QTY PART NUMBER DESCRIPTION
1 1 - HYDRAULIC PISTON ASSEMBLY (SEE PAGE 60)
2 1 HI-05301 HYDRAULIC CYLINDER
3 2 HI-05200-3 PORT BLOCK, HYDRAULIC
4 2 - HYDRAULIC SEAL ASSEMBLY (SEE PAGE 59)
5 2 HI-05302 FEMALE CLEVIS
6 2 HI-05303 SWITCH PLATE
7 2 OR-00040A O-RING -036 HYD CYLINDER
8 1 HI-05322 FLANGE RTAINER, “A” SIDE
9 1 HI-05333 FLANGE RETAINER, “R” SIDE
10 4 201580 WASHER, FLAT, 5/16, 18-8 SS
11 4 201591 FHCS, #8-32 X 0.375, 18-8 SS
12 2 HI-05337 SPRING PIN, SLOTTED 1/8” DIA
13 4 202145 WASHER, LOCK, 5/16, 18-8 SS
14 4 202212 HHCS, 5/16-18 X 7.00, GRD5
15.7.1 HYDRAULIC CYLINDER REBUILD KIT
HYDRAULIC CYLINDER REBUILD KIT (KT-05200)
ITEM QTY PART NUMBER DESCRIPTION
1 2 HI-05025-1 U CUP
2 2 HI-05025-2 BACK-UP RING, PISTON
3 1 HI-05025-3 WEAR RING
4 2 HI-05025-4 WIPER, ROD
5 2 HI-05025-5 SHAFT SEAL
6 2 HI-05025-6 BACK-UP RING, BUSHING
7 2 OR-00039A O-RING -218 HYD CYLINDER ROD
8 2 OR-00040A O-RING -036 HYD CYLINDER
REVISION 1.2 62
