PMC PH-2 - Pump Rebuild Kit

POLYURETHANE
MACHINERY
CORPORATION
PH-2 SERVICE MANUAL
15. PARTS IDENTIFICATION
PUMP LINE ASSEMBLY - LOW PRESSURE (PL-9)
ITEM QTY PART NUMBER DESCRIPTION
1 4 201584 SHCS, 3/8-16 X 3.000, 18-8 SS
2 4 201585 SHCS, 3/8-16 X 6.000, 18-8 SS
3 4 201589 SHCS, 1/4-20 X 1.000, 18-8 SS
4 2 202192 PUMP, LP, SIDE FEED, PH-2
5 2 HI-05011 6 ORB X 6 JIC
6 2 HI-05334 FLANGE
7 1 HI-05336 HYDRAULIC CYLINDER ASSY, PH(X)-2
8 1 OR-807 O-RING -137, VITON
9 1 PU-01017A-008 120 PUMP CYLINDER SEAL
10 2 PU-05007 PIN, CLEVIS W/ CLIP
10.1 1 201167 E-CLIP, 7/32”
10.2 1 202198 PIN, CLEVIS
11 1 PU-07001 MALE CLEVIS
12 1 PU-07003 LUBE SHAFT
13 1 PU-07007 BRACKET
14 1 PU-07008 LUBE SECTION
15 4 PU-07009 STAND OFF
15.10.1 PUMP REBUILD KIT
PUMP-LINE ASSEMBLY - LOW PRESSURE (PL-9)
QTY PART NUMBER DESCRIPTION
1 KT-PA PH PUMP REBUILD KIT (2,000PSI)
REVISION 1.2 67
