PH-2 SERVICE MANUAL
15. PARTS IDENTIFICATION
PROPORTIONER HOSES
ITEM QTY PART NUMBER DESCRIPTION
1 4 HI-05047-2 HOSE 9” HYD PUMP TO TANK
2 2 HI-05047 HOSE, PUMP TO HEATER
3 1 HI-05047-8 HOSE ASSY
4 1 HI-05013 HOSE 1/2 X 2 HYD TANK RETURN
5 1 HI-05047-4 HOSE 13” TOP PUMP CYL
15.17.1 HALF INCH HOSE KIT
HALF INCH HOSE KIT (200599)
PART NUMBER DESCRIPTION QTY
200600 6 ORB X 8 JIC 1
200601 6 ORB X 10 JIC 1
200602 6 ORB X 8 JIC 90 DEG 1
200603 6 ORB X 10 JIC 90 DEG 1
RA-00019 JIC REDUCER 7/8-14 X 9/16-18 1
RA-00020 JIC REDUCER 3/4-16 X 1/2-20 1
REVISION 1.2 83
