PH-2 SERVICE MANUAL
15. PARTS IDENTIFICATION
15.2 PROX SENSOR ASSEMBLY
Figure 12: Prox Sensor Assembly (RM-243)
PROX SENSOR ASSEMBLY (RM-243)
ITEM QTY PART NUMBER DESCRIPTION
1 2 201060 WASHER, LOCK, 1/4, 18-8 SS
2 2 201621 WASHER, FLAT, 1/4, 18-8 SS
3 2 201930 HHCS, 1/4-20 X 1.0, ZP GRD8
4 1 EL-153 12MM PROX SWITCH
5 2 EL-153-01 HEX JAM NUT, M10
6 1 PU-07006 PROX SWITCH MOUNT
REVISION 1.2 56
