PH-2 SERVICE MANUAL
15. PARTS IDENTIFICATION
FRAME ASSEMBLY (FR-10)
ITEM QTY PART NUMBER DESCRIPTION
1 1 200950 GROMMET, 1.750” GD, 0.375” GW, 1.500” ID
2 2 200951 GROMMET, 1.000” GD, 0.125” GW, 0.813” ID
3 24 201060 WASHER, LOCK, 1/4, 18-8 SS
4 2 201328 GROMMET, 2.250” GD, 0.125” GW, 2.000” ID
5 8 201560 BHCS, 1/4-20 X 0.5, 18-8 SS
6 4 201583 SHCS, 3/8-16 X 2.0, 18-8 SS
7 2 201590 BHCS, #8-32 X 0.5, 18-8 SS
8 24 201621 WASHER, FLAT, 1/4, 18-8 SS
9 4 201627 WASHER, FLAT, 3/8, 18-8 SS
10 4 201628 WASHER, LOCK, 0.375, 18-8 SS
11 4 201899 BHCS, 1/4-20 X 0.75, 18-8 SS
12 4 201902 BHCS, 1/4-20 X 1.0, 18-8 SS
13 4 201904 BHCS, 3/8-16 X 2.25, 18-8 SS
14 16 201930 HHCS, 1/4-20 X 1.0, ZP GRD8
15 2 EL-000P12 HAYCO #6 AWG SR
16 1 EL-000P7 HAYCO SR THERMOCOUPLE
17 1 HI-00001A SIGHT GAUGE
18 1 HI-00002-A-1 GROMMET MODIFIED 1”
19 1 HI-00014-03A TANK TOP GASKET
20 1 HI-00047A HYDRAULIC FILL STRAINER
21 4 HI-001 PLASTIC TUBE CAPS
22 1 HI-05306 TANK PUMP DRAIN TUBE
23 1 HI-05308 TANK DISCHARGE TUBE
24 1 HI-05317 3/8 JIC BULKHEAD UNION
25 1 HI-05319 1/2 JIC BULKHEAD UNION
26 1 MQ-01008A LUBE BOTTLE BRACKET
27 1 RM-05700-11 TANK LID
28 1 RM-05700-15 MOTOR MOUNT BARS
29 1 RM-238 TANK
30 1 RM-240 FRAME BASE ASSY
31 1 RM-241 FRAME UPRIGHT
32 1 TN-05704 4” CASTER
REVISION 1.2 55
