POLYURETHANE
MACHINERY
CORPORATION
PH-2 SERVICE MANUAL
15. PARTS IDENTIFICATION
PREHEATER ASSEMBLY
PH-33 (7000W)
ITEM QTY PART NUMBER DESCRIPTION
1 4 201560 BHCS, 1/4-20 X 0.500, 18-8 SS
2 4 201899 BHCS, 1/4-20 X 0.750, 18-8 SS
3 4 201561 BHCS, #6-32 X 0.375, 18-8 SS
4 2 EL-00006A OVERTEMP SWITCH
5
8 GM-05423-1250 FIRE ROD, 1250W, 3/4 NPT, 17.5”
8 GM-05423-1500 FIRE ROD, 1500W, 3/4 NPT, 17.5”
5
8 GM-05423-1750 FIRE ROD, 1750W, 3/4 NPT, 17.5”
6 8 GM-05423-7 SPRING 18”
7 4 GM-07004 HEATER SPACER
8 2 GM-07005 HEATER MOUNT
9 1 GM-07006 8 ROD HEATER BODY
10* 2 HI-05020 THERMOCOUPLE NUT
11* 2 HI-05021 E TYPE THERMOCOUPLE
12 6 HI-05033 8 ORB PLUG
13 8 HI-05034 12 ORB PLUG
14 2 HI-05036 1/4 NPT FLUSH SEAL PIPE PLUG
15 4 HI-05352 8 ORB X 6 JIC
* Indicates part included in KT-05021: Heater Thermocouple Kit
REVISION 1.2 74
