Polycom SoundStation IP 5000 User Manual

1 - 4
The following figure shows how to connect your phone to the network using
optional AC power.
To connect the phone using AC power:
1. Connect one end of the 25-foot Network Cable to the LAN jack on the
phone.
2. Connect the other end of the 25-foot Network Cable to the
Power Insertion Cable.
3. Connect the Power Insertion Cable to an available LAN port on the wall
or hub/switch device port.
4. Connect the Power Adapter to the Power Insertion Cable.
5. Connect the Power Adapter (with the attached Regional Power Cord) to
the wall outlet.
Registering the Phone
Generally, your phone will be deployed with multiple other phones. In this
case, your system administrator will configure the phone parameters
beforehand, so that after you set up your phone, the phone will be registered
and ready to use.
2
3
4
5
1
Power Adapter
Power Insertion Cable
25-foot Network Cable

Polycom SoundStation IP 5000 Specifications

General

Frequency range	250 - 7000 Hz
Power over Ethernet (PoE)	Yes
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN (RJ-45) ports	1
Power consumption (typical)	19 W
Operating temperature (T-T)	5 - 40 °C
Harmonized System (HS) code	85258900

Weight and Dimensions

Weight	520 g
Dimensions (WxDxH)	265 x 285 x 65 mm
