Polycom SoundStation IP 5000 User Manual

2 - 5
3. Press the Select soft key.
4. Press to return to the idle screen.
Updating the Display Contrast
You can set how light or dark the screen appears.
To adjust the contrast on the phone screen:
1. Press , and then select Settings > Basic > Contrast.
The Contrast screen displays.
2. Press the Up or Down soft keys to increase or decrease the display
contrast.
3. Press the Ok soft key.
4. Press to return to the idle screen.
Updating the Backlight Intensity
Backlight intensity on the phone has three components:
• Backlight On
• Backlight Idle
• Maximum Intensity
You can modify the Backlight On intensity and the Backlight Idle intensity
separately. You can select high, medium, low, and off levels for both.
When you modify the Maximum Intensity, you modify the entire backlight
intensity scale. For example, if you decrease the Maximum Intensity, the low,
medium, and high levels for both Backlight On and Backlight Idle intensities
decrease.
The Backlight On intensity applies to the following events:
• Any key press
• Incoming calls
• Ending a call, holding a call, resuming a call by the other party
• A voice message received

Polycom SoundStation IP 5000 Specifications

General

Frequency range	250 - 7000 Hz
Power over Ethernet (PoE)	Yes
Compliance industry standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN (RJ-45) ports	1
Power consumption (typical)	19 W
Operating temperature (T-T)	5 - 40 °C
Harmonized System (HS) code	85258900

Weight and Dimensions

Weight	520 g
Dimensions (WxDxH)	265 x 285 x 65 mm
