Multiple-Monitor Mode
The following table describes each monitor’s expected behavior in
systems using one to four monitors.
Table 5-1. Expected Display for Each Monitor
Condition PIP
Monitor System VGA
or Visual
Concert
VGA
1 2 3 4
Booting None Logo Logo Logo Logo JPEG
Test pattern None Color bar Color bar Color bar Color bar
Single-monitor mode, no VGA
Not in a call: main/UI Near Main
Not in a call: graphic None Graphic
Point-to-point call:
call connect
Near Far
Point-to-point call:
main/UI
Far Main
Point-to-point call:
graphic
Far Graphic
Multipoint call:
main/UI
Last
talker
Main
Multipoint call:
graphic
Last
talker
Graphic
Multipoint call:
discussion mode
None Cont.
presence
Multipoint call:
presentation mode
None Cont.
presence
Multipoint call:
full-screen mode
Near Last
talker
Single-monitor mode, VGA
Not in a call: main/UI Near Main No change
Not in a call: graphic None Near Graphic
