Polycom SoundStation2 EX, FX, VS4000

Integrators’ Reference Manual for ViewStation EX, ViewStation FX, and VS4000
130 www.polycom.com
Small Room Systems
Network interface (4) DCP- clear RJ-45 20 ft (6.1 m), Standard No
DCP interface only DCP Green/white RJ-45 20 ft (6.1 m),
Standard, keyed
No
Table B-9. Cables for Upgrading ViewStation Models (Except FX)
Use Description Length and pinout Longer version
Quad BRI network side (4) Quad BRI - Clear
RJ-45
20 ft (6.1 m), Standard No
V.35 to MP, network (4) DCP - Clear RJ-45 20 ft (6.1 m), Standard No
MP upgrade kit No cables associated with this kit
V.35 module upgrade kit No cables associated with this kit
DCP Module, network
side
(4) DCP- clear RJ-45 20 ft (6.1 m), Standard No
DCP interface only DCP green/white RJ-45 20 ft (6.1 m),
Standard, keyed
No
Table B-10. Cables for ViewStation SP 128
Use Description Length and pinout Longer version
IP network Orange RJ-45 12 ft (3.7 m), standard No
Microphone pod Brown RJ-9 30 ft (9.1 m), standard No
ISDN network Green RJ-45 20 ft (6.1 m), standard No
Monitor Triple RCA with S-video 6 ft (1.8 m), standard No
Table B-8. Cables for ViewStation MP DCP (Continued)
Use Description Length and pinout Longer version
