Appendix B - ViewStation Series Cables
© Polycom, Inc. 129
Table B-7. Cables for ViewStation MP
Use Description Length and pinout Longer version
IPOTS Pink RJ-11 12 ft (3.7 m) No
IP network Orange RJ-45 12 ft (3.7 m), Standard No
PC Ethernet Blue RJ-45 25 ft (7.6 m), Standard No
Audio device input Black single RCA 8 ft (2.4 m), Standard No
VCR Red/white/yellow RCA 8 ft (2.4 m), Standard No
Second monitor Yellow S-video 8 ft (2.4 m), Standard No
Document camera Yellow S-video 25 ft (7.6 m), Standard No
Microphone pod Brown RJ-9 30 ft (9.1 m), Custom No
ISDN network Green RJ-45 20 ft (6.1 m), Standard No
Monitor Triple RCA with S-video 6 ft (1.8 m), Standard No
Network interface (4) Quad BRI - clear
RJ-45
20 ft (6.1 m), Standard No
Table B-8. Cables for ViewStation MP DCP
Use Description Length and pinout Longer version
IPOTS Pink RJ-11 12 ft (3.7 m) No
IP network Orange RJ-45 12 ft (3.7 m), Standard No
PC Ethernet Blue RJ-45 25 ft (7.6 m), Standard No
Audio device input Black single RCA 8 ft (2.4 m), Standard No
VCR Red/white/yellow RCA 8 ft (2.4 m), Standard No
Second monitor Yellow S-Video 8 ft (2.4 m), Standard No
Document camera Yellow S-Video 25 ft (7.6 m), Standard No
Microphone pod Brown R-J9 30 ft (9.1 m), Custom No
ISDN network Green RJ-45 20 ft (6.1 m), Standard No
Monitor Triple RCA with S-video 6 ft (1.8 m), Standard No
