Polycom SoundStation2 EX, FX, VS4000 User Manual

© Polycom, Inc. 135
Index
A
acoustics 73
address
E.164 56
H.323 (IP) 56
administration plan 58
Adtran Atlas 800 Plus E1 module 82
ARENA API 19, 20
audio codecs 17
audio quality 17, 73
B
bandwidth
allocation policy 58
PRI E1 26
PRI T1 26
requirements
calculating 50
browser, see Web browser 19
C
cable
adapter
coaxial, for ViewStation FX/VS4000
PRI 83
ViewStation FX/VS4000 V.35/RS-
449 31
Ascend HD-44M to HD-44M Y 36
diagram 36
pinout 36
crossover, network interface module to
PBX 80, 83
extension
ViewStation FX/VS4000 to network
interface module 83
for direct connect 85
HD-44M to DB-25M/RS-366 and DB-
37M/RS-449/422 85
HD-44M to DB-25M/RS-366 and M34
Winchester V.35 85
HD-44M to HD-44M 85
HD-44M to RS-366 Y 32, 33
diagram 32
pinout 33
HD-44M to RS-449/RS-422 Y 34, 35
diagram 34
pinout 35
not supported 23, 29
PRI to network 84
Quad BRI to network 24
RS-232 for ViewStation FX
diagram and pinout 20
RS-232 for VS4000
diagram and pinout 21
V.35/RS-449
for encryption equipment 44
ViewStation FX/VS4000 Quad BRI to
network
diagram and pinout 24
ViewStation FX/VS4000 to network
interface module 23, 83, 84
diagram and pinout 23
call
cascading 18
multipoint 18, 98, 99, 100, 101, 102, 103,
104, 105
point-to-point 98, 99, 100, 101, 102, 103,
104
test 96
call blocking 27
call routing 57
caller ID 27
camera 16
camera presets 16

Polycom SoundStation2 EX, FX, VS4000 Specifications

General

Device Type	Conference phone
Microphone Pickup Range	360 degrees
Display	Backlit LCD
Echo Cancellation	Yes
Power Source	AC power adapter
Connectivity	Analog phone line
