Integrators’ Reference Manual for ViewStation EX, ViewStation FX, and VS4000
32 www.polycom.com
V.35/RS-449/RS-530 Cabling
This section provides cable drawings and pinouts for the three
cables that you can use with the V.35/RS-449/RS-530 network
interface module. All are common to the ViewStation EX,
ViewStation FX, and VS4000.
Figure 2-7. HD-44M to RS-366/V.35 “Y” Cable Diagram
Table 2-20. V.35/RS-449/RS-530 Network Side Indicator Lamps
Indication Meaning
Amber LED on Network interface module is connected to the
network and receiving a clock signal
Green LED on System is in a call

Polycom SoundStation2 EX, FX, VS4000 Specifications

General

Device Type	Conference phone
Microphone Pickup Range	360 degrees
Display	Backlit LCD
Echo Cancellation	Yes
Power Source	AC power adapter
Connectivity	Analog phone line
