Integrators’ Reference Manual for ViewStation EX, ViewStation FX, and VS4000
126 www.polycom.com
Table B-2. Cables for ViewStation EX and ViewStation FX
Use Description Length and pinout Longer version
PC Ethernet Blue RJ-45 25 ft (7.6 m), Standard No
IP network Orange RJ-45 12 ft (3.7 m), Standard No
Audio device input Single black RCA 8 ft (2.4 m), Standard No
Document camera Yellow S-video 25 ft (7.6 m), Standard No
Second monitor Yellow S-video 8 ft (2.4 m), Standard No
VCR Red/white/yellow RCA 8 ft (2.4 m), Standard No
Microphone pod Brown RJ-9 10 ft (3 m) Custom 30 ft/9.1 m
Monitor Triple RCA with S-video 6 ft (1.8 m), Standard No
ISDN network Light blue RJ-45 20 ft (6.1 m),
Standard, keyed
No
XGA projector or monitor
For FX only
XGA breakout 1 ft (0.3 m) Custom No
Serial Yellow 8-pin DIN to DB-9 10 ft (3 m) Custom No
Camera or camera
control
For FX only
Yellow 8-pin DIN to 8-pin
DIN/4-pin DIN
50 ft (15.2 m)
Standard
100 ft/30.5 m
IPOTS Pink RJ-11 12 ft (3.7 m) No
Table B-3. Cables for Upgrades to ViewStation EX, ViewStation FX, and
VS4000
Use Description Length and pinout Longer version
Quad BRI network side (4) Quad BRI - clear
RJ-45
20 ft (6.1 m), Standard No
Quad BRI to ViewStation
EX or FX
Light blue to green RJ-45 20 ft (6.1 m),
Standard, keyed
No
V.35 module upgrade No cables are associated with this upgrade kit
PRI module network side Quad BRI - Clear RJ-45 20 ft (6.1 m), Standard No
