Polycom Vortex EF2211 User Manual

This command sets or queries the amount of time (in milliseconds) that the front panel buttons must
be idle before the screen saver starts.
This command is an integer command. See
Section 6.2 for more information on this type of
command. The minimum and maximum values for this command are 500 and 600000, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description Status Message
S01SSSTART2000
Set screen saver start time to 2
seconds (2000 ms).
S01SSSTART2000
S01SSSTART>500
Increase screen saver start time
by 0.5 seconds (500 ms).
S01SSSTARTx , where x is the new value of
the screen saver start time. If this command
was issued after the example above, then the
status message would be S01SSSTART2500 .
S01SSSTART?
Query screen saver start time.
S01SSSTARTx , where x is the new value of
the screen saver start time. If this command
was issued after the example above, then the
status message would be S01SSSTART2500 .
8.149. SSTEXT -- Set Text to be Displayed by Screen Saver
This command sets or queries the text messages displayed by the screen saver. The arguments of this
command are the screen number, the line number, and the text to be displayed. The screen number
must be between 0 and 3. It indicates which message screen we are trying to set or query. Each
message screen consists of two lines of text that can be up to 16 characters long. The second number
indicates which line of the message we are tring to set or query. The line number must be 0 or 1
corresponding to the first and second line, respectively. Finally, the text argument is the actual text
that will be displayed on the LCD. If the text is '?', then a query will be performed. If the text empty,
then the message will be cleared. If both message lines are cleared for a given screen, then that
screen will not be displayed by the screen saver. If all screens have been cleared, then the screen
saver will never start (although it is easier just to use the
SSEN command for this).
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description Status Message
S01SSTEXT0,0,Play that
Set the first line of
the first screen to
read "Play that".
S01SSTEXT0,0,Play that
S01SSTEXT0,1,funky music
Set the second line
of the first screen to
read "funky music".
S01SSTEXT0,1,funky music

Polycom Vortex EF2211 Specifications

Power

input voltage	110-240 VAC
frequency	47-63 Hz
power consumption	25 W
phantom power	24 V

Connectors

RS-232	DB9F
EF Bus In/Out	RJ45
Telephone Line/Set	RJ11
Control/Status	DB25F
Audio	3.5mm quick connect terminal blocks

Audio Specifications

microphone input	-30 dBu to +0 dBu
line inputs	-20 dBu to +0 dBu
line outputs	-20 dBu to +0 dBu
loudspeaker output	10 W, 4-16 Ohms
input impedance	10 k Ohms
output impedance	50 Ohms
headroom	20 dB
signal to noise ratio	85 dB
frequency response	20 Hz - 22 kHz

Echo and Noise Cancellation

total cancellation	65 dB
convergence rate	40 dB/second
noise cancellation	0-15 dB
echo cancellation	40 dB, total >65 dB
convergence	30 dB/second
cancellation span	32 ms
acoustic echo cancellation span	270 ms

Operating Environment

operating temperature	0 °C - 40 °C
status outputs	5 V, 20 mA each

Weight and Dimensions

width	483 mm
length	244 mm
height	45 mm
weight	1.8 kg
shipping weight	2.5 kg
