channels 1 and T (the telephone input) .
Using the wildcard character, '*', to specify the channel with this command is not supported for the
EF2211. To set or query the command, the channels must be specified explicitly (e.g., 'S01AGC1?',
'S01AGCT0').
This command is a channel boolean command. See
Section 6.3 and Section 6.1 for more information
on this type of command.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description Status Message
S01AGC11
Enable AGC on input channel 1 .
S01AGC11
S01AGCT0
Disable AGC on input channel T .
S01AGCT0
S01AGC12
Toggle AGC state on input channel 1 .
S01AGC1x , where x is 0 or 1 depending on the
current state of the AGC on input channel 1 .
S01AGCT?
Query AGC state on input channel T .
S01AGCTx , where x is 0 or 1 depending on the
current state of the AGC on input channel T .
8.6. AGCMAX -- Set Maximum Allowed Mic/Line Input AGC
Gain
This command sets the maximum gain that the AGC can apply on input channels 1 and T (the
telephone input) . For example, if AGCMAX is set to 10, then the AGC for that channel can apply a
maximum of 10 dB of gain to the input signal.
Using the wildcard character, '*', to specify the channel with this command is not supported for the
EF2211. To set or query the command, the channels must be specified explicitly (e.g.,
'S01AGCMAX1?', 'S01AGCMAXT7').
This command is a channel integer command. See
Section 6.3 and Section 6.2 for more information
on this type of command. The minimum and maximum values for this command are 0 and 15,
respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description Status Message
S01AGCMAX13
Set AGC maximum gain on input
channel 1 to 3 dB.
S01AGCMAX13
