Polycom Vortex EF2211 User Manual

S01LOA10,MUTEI*1+-.
Configure the conditions for activation of logic
output 10 as described in the example above.
S01LOA10,MUTEI*1+-.
S01LOA7,
Delete conditions for activation of logic output
7.
S01LOA7,
8.87. LOD -- Define Behavior for Logic Output Deactivated
Status
This command is used to define the conditions under which a given logic output pin goes into the
deactive state. The syntax and behavior of this command is identical to that of the
LOA command.
Please refer to the description of the
LOA command for more information, including examples.
This command is saved to global non-volatile memory and is not part of a preset. Its value is saved
each time it is changed. It will retain its value after power-down. Since this command writes to non-
volatile memory, there will be a delay before an acknowledgment is returned.
8.88. LOEN -- Enable Automatic Logic Output Status
Messages
This command controls whether or not logic output status messages are sent automatically. If LOEN is
enabled, then a logic output query (LO*?) is performed any time any of the states change on the
logic output pins. For example, if all logic outputs are currently in the low state ('0') and LOEN is
enabled, then if logic output 12 changes state to '1', the following status message will be generated:
S01LO*00000000000100000000
A status message is only generated if there is a state change. This helps keep data traffic to a
minimum.
This command is a boolean command. See
Section 6.1 for more information on this type of command.
This command is saved to non-volatile memory only as part of a preset. The state of this command
will be restored after power-up only if a preset is saved and that preset is set to be the power-on
preset.
Example Description Status Message
S01LOEN1
Enable automatic logic output status messages.
S01LOEN1
S01LOEN0
Disable automatic logic output status
messages.
S01LOEN0
S01LOEN2
Toggle automatic logic output status messages.
S01LOENx , where x is 0 or 1
depending on the current setting of
LOEN.

Polycom Vortex EF2211 Specifications

Power

input voltage	110-240 VAC
frequency	47-63 Hz
power consumption	25 W
phantom power	24 V

Connectors

RS-232	DB9F
EF Bus In/Out	RJ45
Telephone Line/Set	RJ11
Control/Status	DB25F
Audio	3.5mm quick connect terminal blocks

Audio Specifications

microphone input	-30 dBu to +0 dBu
line inputs	-20 dBu to +0 dBu
line outputs	-20 dBu to +0 dBu
loudspeaker output	10 W, 4-16 Ohms
input impedance	10 k Ohms
output impedance	50 Ohms
headroom	20 dB
signal to noise ratio	85 dB
frequency response	20 Hz - 22 kHz

Echo and Noise Cancellation

total cancellation	65 dB
convergence rate	40 dB/second
noise cancellation	0-15 dB
echo cancellation	40 dB, total >65 dB
convergence	30 dB/second
cancellation span	32 ms
acoustic echo cancellation span	270 ms

Operating Environment

operating temperature	0 °C - 40 °C
status outputs	5 V, 20 mA each

Weight and Dimensions

width	483 mm
length	244 mm
height	45 mm
weight	1.8 kg
shipping weight	2.5 kg
